The LightWave Single Color LED Sheet delivers bright, uniform illumination across a wide CCT range (1800K–6500K). With 420 high-density LEDs and an output of up to 1800 lumens, it’s ideal for signage, displays, and architectural lighting. Compact, efficient, and built for professional installations.
LightWave Single Color Flexible LED Sheet
Out of stock
Description
The LightWave Single Color LED Sheet offers professional-grade, consistent illumination with a range of available CCT options from 1800K candlelight warmth to 6500K crisp daylight. Built in a compact sheet format, it’s perfect for signage, architectural accents, and display backlighting.
Key Features
- Wide CCT Range (1800K–6500K) – Select the precise color temperature required
- High Brightness (1230–1800 lumens) – Reliable illumination output
- Energy Efficient (105–120 lm/W) – With lower efficiency at 1800K (82 lm/W)
- High CRI >80 – Maintains natural color rendering
- Compact Sheet Format – 9.25’’ x 19.8’’ for easy integration
- Dense LED Grid – 420 LEDs provide uniform lighting
Technical Specifications
| Specification | Details |
| Size | 9.25’’ x 19.8’’ (235 x 503mm) |
| Type | Sheet |
| Color Options | 1800K, 2700K, 3000K, 3500K, 4000K, 5000K, 6500K |
| Power Consumption | 15W |
| Power / Area | 12W / sqft • 127W / m² |
| Efficiency | 105–120 lm/W • 82 lm/W (1800K) |
| Light Output | 1230 – 1800 lumens |
| Light Output / Area | 1000 – 1400 lm/sqft • 11,000 – 15,200 lm/m² |
| CRI | >80 |
| LED Quantity | 420 |
| LED Density | 330 LEDs/sqft • 3550 LEDs/m² |
Applications
- Signage & Backlighting – Ideal for branding and display panels
- Architectural Lighting – Flexible and compact solution for accents
- Retail Displays – Consistent single-color illumination
- Exhibit Design – Perfect for clean, simple backlighting
