The LightWave CH2 Tunable White LED Sheet offers dynamic control from 2700K to 6500K, ideal for architectural, retail, and hospitality lighting. With 400 LEDs delivering up to 1540 lumens and 110 lm/W efficiency, it ensures bright, uniform, and energy-efficient illumination in a compact 12’’ x 24’’ flexible sheet.
LightWave CH2 Tunable White Flexible LED Sheet
Out of stock
Description
Introduction
The LightWave CH2 Tunable White Sheet is engineered for lighting designers who need dynamic control over white tones while maintaining professional-grade brightness and efficiency. With a range of 2700K to 6500K, this flexible sheet adapts to both warm ambient settings and bright functional environments.
Compact yet powerful, this 12’’ x 24’’ ultra-thin LED sheet outputs up to 1540 lumens with efficiency up to 110 lm/W, making it ideal for architectural backlighting, signage, and retail spaces.
Key Features
- 2700K–6500K Tunable White – Full flexibility for ambiance or daylight.
- High Efficiency (100–110 lm/W) – Energy savings without compromising output.
- Strong Lumen Output – 1400–1540 lumens for reliable illumination.
- High CRI >80 – Ensures accurate color rendering.
- Compact 12’’ x 24’’ Sheet – Easy integration into small or large projects.
- Dense LED Grid – 400 LEDs for uniform brightness.
Technical Specifications
| Specification | Details |
| Size | 12’’ x 24’’ (305 x 610mm) |
| Type | Flexible LED Sheet |
| Color Temperature (CCT) | 2700K – 6500K |
| Power Consumption | 14W / color |
| Power / Area | 7W / sqft • 75W / m² |
| Efficiency | 100 – 110 lm/W |
| Light Output | 1400 – 1540 lumens |
| Light Output / Area | 700 – 770 lm/sqft • 7500 – 8250 lm/m² |
| CRI | >80 |
| LED Quantity | 400 (2 x 200) |
| LED Density | 200 LEDs/sqft • 2150 LEDs/m² |
Applications
- Architectural Projects – Perfect for wall, ceiling, and accent backlighting.
- Retail Displays – Showcase products with flexible white tones.
- Hospitality & Dining – Adjust ambiance lighting to guest needs.
- Museums & Exhibits – Dynamic lighting for rotating displays.
